Schneider Electric BMXAMI0800 High-Speed, Non-Isolated Analog Input Module
$ 102.96
Description
Schneider Electric BMXAMI0800 High-Speed, Non-Isolated Analog Input Module. Comparison: BMXAMI0800 vs. BMXAMI0810., which provides isolated channels. Input Channels: 8 high-level analog inputs. TheSchneider Electric. The Schneider Electric BMXAMI0800 is a high-speed, non-isolated analog input module designed for the Modicon X80 platform. It is fully compatible with both Modicon M340 and M580 Programmable Automation Controllers (PAC). Key Technical Specifications This module is engineered for medium to large process applications that require fast data acquisition without the need for channel-to-channel isolation. Input Channels: 8 high-level analog inputs. Resolution: 15 bits + sign (16-bit analog/digital conversion). Input Types: * Voltage: +/- 10 V, +/- 5 V, 0...10 V, 0...5 V, 1...5 V. Current: +/- 20 mA, 0...20 mA, 4...20 mA. Speed: Fast read cycle time of 1 ms + 1 ms per channel used ; nominal cycle time is 9 ms for all 8 channels. Accuracy: Precision of 0.1% at 25°C for most voltage ranges. Connection: Requires a 28-way single connector (removable terminal block or pre-wired cord sets). Isolation: 1400 V DC between channels and ground/bus, but no isolation between individual channels . Comparison: BMXAMI0800 vs. BMXAMI0810 If your application involves potential ground loops or requires higher signal protection, you might consider the BMXAMI0810 , which provides isolated channels.
